Official Battery Forklift FB30 Certification New Style 3 Ton Electric Forklift Truck with Fork length 1070mm

Date: 2022-04-11 View:

New Style 3 ton Electric Forklift FB30 Pneumatic tires Electric Forklift with CE Certification



High Quality Electrical Components
Original imported world famous brand controller. After professional adjustment, walking and upgrade control is precision and efficiency, excellent performance. The forklift with regenerative braking, ramp braking,fault self-diagnosis and other functions.



Reliable Steering System
Using dynamic load sensing priority steering system, steering response more quickly, driving more smoothly.
Comfortable Operating Space
Ergonomic full-scale operation space layout optimization, which offers operator excellent,comfortable and convenient operating experience.



Efficient Drive System
Advanced H-type remote drive unit, compact structure, lower gravity center, more reasonable layout, more stable driving.



Battery Side-take Function
Fully open hood, it can quickly remove from both side. Hinge design frame side door. The using of advanced design concept of battery replacement program, gives fast and convenient maintenance.



Product Parameters


Model



           FB30

Power Type



          Electric

Rated Capacity

                 KG

           3000

Load Centre

                 MM

           500

Lift Height

                 MM

             3000

Fork Size

                 MM

      1070*125*45

Front Overhang

                 MM

             480

Tread

                 MM

         1000/980

Ground Clearance

                 MM

             120

Fork Spread

                 MM

         250/1100

Length to face of fork

                 MM

            2610

Overall Width

                 MM

           1230

Mast Lowered Height

                 MM

           2115

Mast Extended Heigh

                 MM

           4180

Overall Guard Height

                 MM

           2250

Turning Radius(outside)

                 MM

           2350

Min. insecting aisle

                 MM

           2425

Mast Tilt Angle

                  Deg

         6°/12°

Certificate



The Video of Product
