Date: 2024-12-13 View:

Enhanced Efficiency: Why Choose a Man-Mounted Turret Stacker?

FLIFT, an advanced man-mounted turret stacker equipped with mechanical rail technology.
This impressive machine is tailored for heavy-duty applications with an impressive maximum load capacity of 1.6 tons!


The FLIFT features a robust three-stage frame designed to enable impressive versatility when lifting operations are being undertaken.
Boasting an impressive main lifting height of 8.5 meters and an additional lifting height of 1.7 meters,
its total lifting height reaches 10.2 meters; making it suitable for high stacking environments.

 A FLIFT powered by an 80V 560Ah lead-acid battery ensures long operation periods with minimum downtime.
For added safety and precision during use, this model features a HD wireless camera along
with an HD reversing image function for improved safety and precision during operation.

 One key feature is its one-button linkage function, which simplifies operations by coordinating movements between walking and lifting.
Furthermore, its OPS system enhances overall efficiency by permitting simultaneous raising or lowering loads.

 Additionally, an external charger enables rapid recharging for seamless workflow.
FLIFT represents the pinnacle of warehouse management solutions by raising productivity and safety standards during material handling operations.





Product Feature Introduction

1. The driver can go up with the cab for stacking and picking operation,
with a good vision to improve work efficiency;

2. Advanced American Curtis controller, more stable and reliable, higher efficiency;

3. The core hydraulic components choose imported brands, higher precision, more stable performance;

 4.  Integrated operation panel, high pre-selection, one-key linkage, synchronous  descent,
one-key pick up and put the goods and other semi-automatic functions,
can be integrated operation, good man-machine engineering, driving is not easy to fatigue,
safe and convenient operation, functional switch button entity button, feel good, not easy to misoperation, safe and reliable;


5.  Synchronous walking and lifting down function, forklift lifting down and

walking can be synchronized operation, while the walking speed decreases with the increase of lifting height,
ensure efficiency and greatly improve operationsafety;

6. One-key linkage function of fork rotation can realize fork rotation and lateral

movement at the same time, improve operation efficiency and reduce labor intensity;

7. The main and deputy door frame synchronous descent function,
the main and deputy door frame can drop at the same time,
greatly improve the operationefficiency, reduce labor intensity;

 8. Automatic pickup and release function, one button automatic pickup, one

button automatic release function, greatly improve operating efficiency,
reduce the labor intensity of the driver, with high pre-selection function to greatly improve operating efficiency;

9.  Equipped with all-wheel electromagnetic braking, braking effect is better, emergency braking safety is higher;

10.  The use of 80V ac maintenance-free system, the vehicle more rapid and

accurate response, small current, low energy consumption,
meet the requirements of heavy working conditions, low maintenance cost;

11. Reasonable ergonomics design, lifting folding seats,
adjustable Angle and height of the operating platform, better meet the picking,
stacking operation station driving and driving operation requirements;

12. Front-mounted secondary door frame design, the driver picking operation space is larger, more safe;

13.  With both hands sensing and pedal sensing OPS system,
only when the driver holds the accelerator lever and pushes the pedal at the same time,
the forklift can move, to ensure the safety of the driver;

14. Arm guard lift protection, only after the arm guard down, forklift can operate, improve safety;

15. HD reversing image function, can see the rear of the vehicle and the rear of   the left and right sides of the vision,
standard rear blue light and warning lights, improve the safety of vehicle operation;



16. Optional magnetic navigation roadway mode, height pre-selection, roadway protection and other semi-automatic
and safety functions, to meet customer needs to the greatest extent;

17.  Multi-functional LCD instrument, rich display, driving wheel Angle,
fork height, battery power, driving speed and other information dynamic display, easier to operate.





 1. What is the maximum lifting height of the FLIFT turret stacker?

   The FLIFT turret stacker has a main lifting height of 8.5 meters,
with an auxiliary lifting height of 1.7 meters, providing a total lifting height of 10.2 meters.

2. What is the rated load capacity of the FLIFT turret stacker?

   The FLIFT man-mounted turret stacker is rated for a load capacity of 1.6 tons,
making it suitable for handling substantial loads in narrow aisle applications.


3. How does the OPS system enhance safety during operation?

   The OPS (Operator Presence System) ensures that operations can only be conducted when the operator is in position,
significantly enhancing user safety while maneuvering in tight spaces.


4. What features contribute to improved visibility and safety while operating the turret stacker?

   The HD wireless camera and HD reversing image function provide enhanced visibility around the truck,
allowing operators to navigate safely even in very narrow aisles.


5. Can I charge the battery externally, and what type of Man mounted VNA truck battery is used?

   Yes, the FLIFT turret stacker utilizes an 80V 560Ah lead-acid battery
that can be charged externally for convenience and efficiency during downtime.


6. What are the advantages of synchronous walking and lifting functionsfor the VNA trucks?

   Synchronous walking and lifting allow operators to move vertically while navigating horizontally simultaneously,
improving productivity and reducing cycle times in material handling tasks.




7. Is there any special training required to operate the FLIFT turret stacker effectively?

   While basic training on lift operations is recommended,
specific operational training focusing on utilizing its advanced features like one-button linkage function
should be provided to ensure optimal performance.



8. In what environments are narrow aisle fork trucks most effective?

   The FLIFT man-mounted turret stackers are designed for very narrow aisle environments commonly found in warehouses
and distribution centers where space optimization is critical for efficient stacking and retrieval operations.
